Eye Shower, Bench-Mounted, Swivel Joint, Left of Sink

Item no.:
17530009

The bench-mounted double eye shower is designed for simultaneous rinsing of eyes and face. The unit is designed for mounting on the left side of the sink, with the ability to turn to the side for full sink access when not in use.

This item: Eye Shower, Bench-Mounted, Swivel Joint, Left of Sink
This item: Eye Shower, Bench-Mounted, Swivel Joint, Left of Sink
This item: Eye Shower, Bench-Mounted, Swivel Joint, Left of Sink

Description

The bench-mounted double eye shower is designed for simultaneous rinsing of eyes and face. Equipped with easy-clean spray heads, it effectively reduces limescale build-up, ensuring optimal performance and longer product lifespan. The integrated dust caps tightly seal the spray heads, preventing dust and particles from entering. Once opened during use, the dust caps stay in position, allowing uninterrupted rinsing. The unit is designed for mounting on the left side of the sink, with the ability to turn to the side for full sink access when not in use. Activation is quick and easy, requiring just one movement to turn the shower into the sink for immediate use. The eye shower is constructed in compliance with EN15154 and ANSI Z358.1 standards, ensuring perfect spray pattern, full safety and reliability. The shower can be easily connected to a BROEN-LAB TMV (Thermostatic Mixing Valve) to ensure a consistent water temperature of 22°C. The built-in FLOWFIX regulates water flow to 12 litres/minute for consistent performance. The unit includes signage in accordance with ISO 3864-1 to clearly mark the position of the shower. Constructed from durable brass with chemical-resistant BROEN-LAB Polycoat, it is optimized for use in a variety of environments. The robust wall-mount flange, featuring six holes, allows for easy installation with a plug-and-play design.

Specifications

Material: Brass, Stainless Steel, Plastics

Colour: Red, Black

Flow rate: 12 litres/minute

Min. operating pressure: 2 bar

Max. operating pressure: 10 bar

Inlet connection: G1/2” female

Inlet hose: M28x1.5



Design and approvals according to:

  • EN15154-2
  • ANSI Z358.1
  • ISO 3864-1



Several global approvals are available.

Downloads

Documents Type File type/size
Customer drawing Product sheet pdf (649.8 kb)
Spare part drawing Product sheet pdf (132.4 kb)
STEP file Product sheet (NAN )
BIM file Product sheet (NAN )
DWG file Product sheet (NAN )
